1.2581 | 3Cr2W8V | 2730 | 3X2B8Φ | H21 | SKD5 | X30WCrV9-3

This kind of steel has high hardness and thermal stability, good wear resistance and hardenability, good wear resistance, fatigue resistance, durability, machinability and weldability, excellent hardenability, and good fatigue resistance.

SKU: N/A Category: Tags: , , , , , ,

Introduction to 1.2581 | SKD5 | H21 | X30WCrV9-3 | 3Cr2W8V | 2730 | 3X2B8Φ

1.2581 (DIN/Germany)

A tungsten-chromium hot-work steel with excellent high-temperature strength (up to 600°C). Contains 0.35% C, 2.5% Cr, and 9% W. Ideal for extrusion dies and forging tools due to its thermal fatigue resistance. Requires proper quenching (oil/air) and tempering. Common in European machinery.

SKD5 (JIS/Japan)

Japanese equivalent of H21, with 9% W and 3% Cr. Offers superior heat resistance for aluminum/copper alloy die casting. Hardens to 50–55 HRC after quenching. Requires tempering at 600–650°C. Popular in automotive and aerospace tooling.

H21 (AISI/USA)

A classic tungsten-chromium hot-work steel (0.35% C, 3.5% Cr, 9% W). Known for red hardness (up to 650°C) and resistance to thermal softening. Used for extrusion dies, hot punches, and glass-molding tools. Prone to decarburization; needs protective atmosphere during heat treatment.

X30WCrV9-3 (AFNOR/France)

French hot-work steel with 9% W, 3% Cr, and 0.3% V. Combines thermal stability (600°C) with good machinability. Used for high-stress forging dies and turbine components. Less common globally but valued for niche high-temperature applications.

3Cr2W8V (GB/China)

Chinese standard steel with 3% Cr, 2% W, and 8% V. Excels in wear resistance and toughness under cyclic heating (500–600°C). Used for die-casting molds, hot shears, and high-pressure valves. Cost-effective for aluminum/magnesium alloy processing.

2730 (AISI/USA)

A medium-carbon hot-work steel with 1.5% Cr and 0.5% Mo. Balances thermal conductivity and shock resistance. Operates up to 540°C. Common in brass/copper alloy forging dies and plastic injection molds. Less alloyed than H21 but easier to machine.

3X2B8Φ (Russian)

Russian-grade steel with 3% Cr, 2% W, and 8% V (similar to 3Cr2W8V). Optimized for high-pressure die casting and hot-stamping tools. Retains hardness at 550–600°C. Requires precise heat treatment to avoid brittleness.

Chemical Composition

1.2581/ H21/3Cr2W8V/SKD5/X30WCrV9-3/2730/3X2B8Φ
Standard/Steel Grade Chemical Composition(%)
C Si Mn Cr V W
DIN/W-Nr. X30WCrV9-3/1.2581 0.25~0.35 0.15~0.30 0.20~0.40 2.50~2.80 0.30~0.40 8.00~9.00
GB 3Cr2W8V 0.30~0.40 ≤0.40 ≤0.40 2.20~2.70 0.20~0.50 7.50~9.00
ASTM H21 0.26~0.36 0.15~0.50 0.15~0.40 3.00~3.75 0.30~0.60 8.50~10.0

Supply Form & Range

The size range of round steel and plates for tool steel

For 1.2581/ H21/3Cr2W8V/SKD5/X30WCrV9-3/2730/3X2B8Φ steel, we can provide round bars and plates. Round rods can be sawn to the length you need and used as single or multiple cut pieces. Grinding tool steel bars can be provided, offering high-quality precision finished bars for strict tolerances.

Product Type Dimensions Range
Round Bar Diameter 16 – 400 mm
Length 3,000 – 5,800 mm
Flat Bar Thickness 16 – 300 mm
Width 200 – 800 mm
Length 3,000 – 5,800 mm

In addition, we can provide a variety of surface conditions of tool steels:BlackPeeled/Grinded;Turned/Machined/Bright/Milled

Customization of core parameters

Depending on your application scenario, we offer a full range of configurable manufacturing:

✓ Geometric size: Support millimeter precision size customization (tolerance ±0.05mm)

✓ Surface treatment: grinding/polishing/sandblasting can be specified (Ra0.4-6.3μm)

✓ Composition optimization: the ratio of C, Cr, Mo, V and other alloy elements can be adjusted (according to ASTM A681 standard)

Quality Test

We have 2 types of quality inspection, general quality test and high quality test.

1.General quality test include:

  • Surface
  • Chemical composition
  • Size
  • Tolerance
  • UT testing
  • Hardness.

2.High quality test include:

Cold work tool steel:

  • Non-metallic inclusion
  •  Eutectic carbide.

Hot work tool steel:

  • Non-metallic inclusion
  • Microstructure
  • Band segregation
  • Grain size.

Packing and Delivery

Secure packaging, reliable shipping, and a robust tracking system ensure safe and timely deliveries.

  • Delivery time: 1 Month
  • Packing:Bundle, or with all kinds of colors PVC or as your requirements

Production Process

Complete production capacity from raw material selection, EF(Electric Furnace),LF(Ladle Furnace),VD(Vacuum Debonding), ESR(Electroslag Remelting), Forging, heat treatment, machining to finished die steel.With complete quality inspection means and various quality inspection equipment, it can ensure that all die steel products are subject to strict quality inspection, flaw detection and metallographic inspection.
EAF+ LF +VD +Ingot Casting +ESR +Forging +Quenching And Temper +Annealing +Ultra Refinement

  • EF+LF+VD:electric furnace+Ladle furnace+vacuum debonding
  • ESR:Electroslag Remelting
  • Forging
  • Ingot Casting
  • Annealing
  • Brandsaw cutting
  • Turning Milling
